GASKET FOR BOILERS

Gasket for boiler guage
Gasket for boiler guage

Gasket Specifications

Gaskets are placed between two adjoining pieces of port glass or positioned around gauge glass to ensure that liquid and hot gases do not escape the boiler. Gaskets prevent unwanted leakage and thereby allow the boiler to operate at optimal efficiency.

United Hardware Mart offers wide range of gaskets for boilers. The dimensions of the gasket must be matched to the dimensions of the gauge glass. Gaskets are made from CAF sheets or graphite plates resistant to temperatures upto 450 °C and the pressure to 150 bar. Popular materials are asbestos-free sealing

The following table presents a gaskets sizes for different sizes of gauge glasses. Dimensions [mm]:
‍

Glass size

TYPE C

TYPE A

TYPE B/H

TYPE TA-28

L

W

L

W

L

W

L

W

0

85

20

95

30

95

34

-

-

I

115

20

115

30

115

34

133

47

II

140

20

140

30

140

34

158

47

III

165

20

165

30

165

34

183

47

IV

190

20

190

30

190

34

208

47

V

220

20

220

30

220

34

238

47

VI

250

20

250

30

250

34

268

47

VII

280

20

280

30

280

34

298

47

VIII

310

20

320

30

320

34

338

47

IX

320

20

340

30

340

34

358

47

X

340

20

370

30

370

34

-

-

XI

360

20

400

30

400

34

-

-

XII

370

20

430

30

430

34

-

-

XIII

400

20

460

30

460

34

-

-

XIV

430

20

500

30

500

34

-

-

s = 0,3

s = 1,3

s = 1,5

Compressed Fiber Jointing Gaskets

‍These gaskets help in creating a perfectly sealed layer of glass by preventing leakage between two adjoining pieces of port glass.

Mica Gasket Assembly

Mica gasket assembly provides effective and thorough sealing for gauge glass

‍At United Hardware Mart we understand that every industrialapplication depends specific types of gasket. We provide custom fabricatedgaskets as per your exact needs.

MICA strips / MICA NITE sheet, Graphite Sleeve and Gaskets fabricated as per custom specifications.

SEND ENQUIRY

United Hardware Mart

United Hardware Mart is a leading supplier of boiler gauge glasses, Mica and boiler components. We cater to industries across various sectors including power plants, sugar industry, cement industry and oil refineries.
